Zaba12 schrieb:
Good morning everyone,

could someone please share some photos showing how water and wastewater pipes pass through floors in concrete or solid construction? Do these pipes run inside a service shaft, or are recesses made in the walls similar to those for electrical cables? I would also appreciate pictures of fully installed supply air ducts for controlled residential ventilation in the walls. I’m having trouble visualizing how these three elements (service shaft, water/wastewater pipes, controlled ventilation supply air ducts) look in or on the wall.

The heating engineer is currently planning everything and asked me where we want to run the ventilation ductwork from the unit in the basement upwards, which of course takes up some space. I would prefer to route everything in one shaft—ventilation, water/wastewater, and the wiring for the photovoltaic system.

Thanks in advance

In our building, utility lines run through drywall partitions. These walls then serve as something like “exterior walls” for built-in cupboards or similar spaces (I hope that makes sense). So, no recesses or boxed-in sections were made in the actual exterior walls.

Construction Staircase and Roof Framework

What does it feel like to walk through the rooms?

The base plaster is complete...

Zaba12 schrieb:
The heating engineer suggested building the wall completely in drywall between the guest WC and the storage room on the ground floor, so the ducts can be hidden there.

I wouldn’t have any concerns about installing that partition wall as a service wall—just as I would do in the bathrooms: the drywall panels would line up perfectly, meaning they would only need to be full height. There would then be a single ceiling opening beneath the sink. But judging by your architect, I’m sure this has already been planned accordingly.

---
